| Features |
| 1. 23HP American Briggs & Stratton VANGUARD gasoline engine. International warranty local service. |
| 2. Italian imported hydraulic parts. Makes HY200 mini loader high configuration and big working flow. |
| 3. Joystick handle. Operating smoothly and comfortably. |
| 4. Steering wheel operated and clear instructions. |
| 5. One left pedal for attachments' lock-in. Two right pedals control machine's speed, stopping and back up. |
| 6. Articulated steering chassis, drive easily. Seat with safety belt, safe and comfortable. |
| 7. Quick hitch joints, HY200 mini loader can attach bucket, digger, auger, backhoe, hydraulic breaker, pallet forks, angle broom, sweeper,lawn mower, snow blower, stump grinder, tree spade, 4 in 1 bucket, leveler, dumping hopper, ripper, grapple , tiller, mixer, stone bucket, trailer, snow blade and so on. One loader can for various function, meet your different jobs. |
\
| Specification |
1)Size | |
Dimension(L*W*H) | 2430mm* 1080mm* 2045mm |
Max pin height(B) | 1755mm |
Max dumping height(C) | 1295mm |
Max point dumping distance(D) | 430mm |
Ground clearance(F) | 210mm |
Wheel base(G) | 1207mm |
Bucket Width | 1150mm |
Total Length without Bucket(J) | 2015mm |
Departure angle(α) | 40° |
Bucket discharge angle | 37° |
Turn Radius forward Turning | 2030mm |
2)Engine | |
Rated Power (KW) | 17.15KW(23HP) |
Type | Gasoline |
3)Hydraulic System | |
Pressure | 17Mpa |
Operating Load | 260kg |
Bucket Capacity | 0.15m³ |
Travel Speed | 0-8km/h |
Weight | 900kg |
Fuel tank capacity | 27.45L |
Hydraulic oil tank capacity | 21L |
Max traction | 5KN |
Max Lifting force | 4.6KN |
· Packaging for LCL: steel frame & plywood packaging |
| · Packaging for LCL |
